Ti5 Robot Brushed Permanent Magnet Servo Motor for Humanoid Robot Arm Joint Model 40-52-2E-101 Dual Encoder Flange Mount 11N.M
Ti5 Robot Brushed Permanent Magnet Servo Motor for Humanoid Robot Arm Joint Model 40-52-2E-101 Dual Encoder Flange Mount 11N.M
Technical Specifications
| Commutation | Brushless |
| Rated Power | 90W |
| Speed Rpm | 40PRM |
| Speed(RPM) | 40PRM |
| IP Rating | IP55 |
| Efficiency | IE 2 |
| Type | Servo Motor |
| Construction | Permanent Magnet |
| Frame | no |
| Motor Mounting Type | Flange Mount |
| Protect Feature | Waterproof |
| Usage | Electric Bicycle, Home Appliance, Smart Home |
| Warranty | 3 months ~ 1 year |
| Continuous Current(A) | 2A |
| Model Number | 40-52-2E-101 |
| Torque | 11N.M(8.11lb.ft) |
| Place of Origin | Shanghai, China |
| Brand Name | Ti5 Robot |
| Selling Units | Single item |
| Single package size | 50X50X50 cm |
| Single gross weight | 8kg |
Tell us about your project and get a customized quote within one business day.
- Custom configurations available
- Global shipping & support
- 1-year warranty included
