Ti5 Robot Brand 120mm Intelligent Artificial Humanoid Robot Joint Module Permanent Magnet Servo Motor 740W Rated Power 40/16 RPM
Ti5 Robot Brand 120mm Intelligent Artificial Humanoid Robot Joint Module Permanent Magnet Servo Motor 740W Rated Power 40/16 RPM
Technical Specifications
| Commutation | Brushless |
| Rated Power | 740w |
| Speed Rpm | 40rpm |
| Speed(RPM) | 40/16RPM |
| IP Rating | IP50 |
| Efficiency | IE 2 |
| Type | Servo Motor |
| Construction | Permanent Magnet |
| Frame | no |
| Motor Mounting Type | Flange Mount |
| Protect Feature | Waterproof |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance, Cosmetic Instrument, Smart Home |
| Warranty | 3 months ~ 1 year |
| Continuous Current(A) | 15.5A |
| Model Number | 60-70-2E |
| Torque | 120/267NM |
| Place of Origin | Shanghai, China |
| Brand Name | Lingheyun |
| Selling Units | Single item |
| Single package size | 30X30X30 cm |
| Single gross weight | 5.0 kg |
Tell us about your project and get a customized quote within one business day.
- Custom configurations available
- Global shipping & support
- 1-year warranty included
